Nerva H2Sep 300
A thinner separator for higher current density in next-generation alkaline stacks.
Products
Separators for alkaline electrolysers, made in India
Nerva H2Sep 500 is available for evaluation now. It drops into 500 µm-class stacks and delivers more current at the same cell voltage.
+38%cell current vs the reference at 2.4 V
430 µma drop-in for 500 µm-class stacks
A4samples available now
Indiadesigned and made in India
Available now
Nerva H2Sep™ 500 alkaline electrolyser separator
A porous, nanomaterial-modified zirconia–polymer composite separator for alkaline water electrolysis. It combines low ionic resistance with high strength, usually a trade-off.
- More hydrogen per stack, or the same output at lower power
- A stronger sheet for assembly and pressure cycling
- Drop-in format: no re-tooling of frames or gaskets expected
- Domestic value addition for India's local-content requirements
- Sizes
- A4 samples now; customer sizes and rolls on request
- Origin
- Made in Indiaभारत में निर्मित
| Property | Nerva H2Sep 500 |
|---|---|
| Thickness | 430 ± 30 µm |
| Ionic resistance | 0.2 Ω·cm² |
| Bubble point | 2.5 ± 1 bar |
| Max. operating temperature | 100 °C |
| Tensile strength vs reference | ≈ 2.7× |
| Cell current vs reference at 2.4 V | +38% (RT), +26% (80 °C) |
Measured at IIT Bombay against a commercial 500 µm-class reference. Typical values, not a specification. The full datasheet is shared under NDA.
Performance data and FAQsComing next
More of the stack, on the same science
Each product is released only when it has been proven with customers. No dates are promised.
High-temperature grade
A separator grade for stacks that run hotter, for higher efficiency.
Electrodes & zero-gap assemblies
Activated nickel electrodes matched to our separator, and assemblies that arrive ready to stack.
AEM membranes
Anion-exchange membranes on the same nanomaterial science, for precious-metal-free electrolysis.
AEM stacks
Anion-exchange-membrane electrolyser stacks with Indian-owned technology.
Develop with us
Early access for stack makers
We develop new grades, electrodes and assemblies with the stack makers who will use them. If you need a thinner sheet, a hotter grade or a ready-to-stack assembly, tell us your design.
- Joint development against your cell design and operating window
- Early samples and shared test protocols
- One supplier for separators, electrodes and assemblies as they launch
Test Nerva H2Sep 500 in your stack.
A4 samples ship in about two weeks, with a certificate of analysis.
